Dual Splitter LGX Module

CL-SA1250021CD

Two optical splitters in a
single-width LGX module.

Customer may specify split ratios
and port connector types.

The Neptec Integra
Broadcast/Narrowcast Combiners

I8DBDR2196
8 Channel Integra
with BC and NC Monitor Ports
(pictured)

Passive optical solutions that allows the combination of broadcast content and discreet narrowcast content. The broadcast stream is divided into X indentical content streams. The narrowcast stream is DeMultiplexed into its X constituent wavelength channels. Then, each of the broadcast streams is combined with a different narrowcast channel.

Customers may specify
NC Wavelengths(CWDM or DWDM)
Channel Count
BC and/or NC Monitor Ports
Connector/Polish Type
Inbound Optical Power Differential
Outbound Optical Power Differential

OviDux WaveRouter 4U4D

OVIDUX-4U4D-C1

Bi-Directional Mux/DeMux.
4 CWDM Channels Upstream.
4 DWDM Channels Downstream.
Monitor Ports for COM In and Out.
Dual-Width LGX Module.

Customer may specify
Wavelength(CWDM/DWDM) Channels,
Port Connector Types,
and Monitor Port Configurations.

1:8 CWDM Mux/DeMux

WCB814702C3E3EG
(pictured)

Bi-Directional Mux/DeMux.
8 CWDM Channels.
120 x 90 x 8 mm Cassette Module.

Customer may specify
Wavelength(CWDM) Channels,
Lead Lengths and Jacketing,
and Connector Types.

Multi-Fiber Cable Assembly

BSMK10ZE1EE1EC
(Pictured)

Multi-Fiber Cable Assemblies made from Outdoor Armored or Non-Armored Cable. Cable ends broken out to individual fiber bundles captured with heat-shrink or fiber entry adapters. 100% end-to-end fiber light-pass testing as well as 100% connector quality inspection.

Customers may specifiy:
Cable Type.
Fiber Count.
Break-Out Jacket Type and Length.
Connector/Polish Type.
Total Length.

2 Channel OADM LGX Module

WDT2IT216LCRCR
(pictured)

2 Channel
Passive Optical Add/Drop
in a single-width LGX module.

Customer may specify:
CWDM or DWDM Channels.
Port Connector Types.
